SONY FCB-ER8300& FCB-CR8300 4K camera block 12x Colour Camera Block

FOB Reference Price:Get Latest Price
$13,000.00 - $20,000.00 / Piece | 1 Piece/Pieces (Min. Order)
1920 x 1080
IP Camera
Box Camera
Report Suspicious Activity
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
Model Number:
CMOS, Progressive scan CMOS Image Sensor 1/2.3 type "Exmor R"
Special Features:
Sony Zoom Block Cameras
Digital Camera
Pan / Tilt / Zoom
Effective pixel:
Approx. 8.93 Mega Pixels
Horizontal Viewing Angle:
73.4° (wide end) to 6.4° (tele end)
Minimum Illumination:
Screen menu:
AWB , Digital noise reduction , Light suppression,Mirror
digital focus:
12x (144x with optical zoom)
Supply Ability
Supply Ability:
14000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard Safety Export Package / Carton (Box + Foam) or as customized
Video Description
Product Description
SONY FCB-ER8300& FCB-CR8300 4K camera block 12x Colour Camera Block

FCB-ER8300 4K camera block

We’ve taken the world leading 4K technology from Sony consumer and professional products and created the worlds first 4K autofocus zoom camera block for the industrial market.

The FCB-ER8300 delivers true 4K resolution at 30fps, and includes 20x zoom capability with advanced zoom technology from Sony.

Utilising Sony Sensor technology and powered by a unique Sony image processor, the FCB-ER8300 can focus on the smallest detail whilst 70 degree HFOV allows for increased situational awareness over large areas.  Perfect for security, surveillance and other industrial applications. Compact form factor and low power consumption allow for easy integration into Pan, Tilt and Zoom camera systems.



Camera SpecificationsDetail:
Image DeviceProgressive scan CMOS Image Sensor 1/2.3 type "Exmor R"
Effective PixelsApprox. 8.93 Mega Pixels
Digital Zoom12x (144x with optical zoom)
Horizontal Viewing Angle73.4° (wide end) to 6.4° (tele end)
Minimum Object Distance10 mm (wide end) to 1,500 mm (tele end) (Default: 300 mm)
Sync SystemInternal
Electronic Shutter1/1 s to 1/10,000 s, 22 steps
White BalanceAuto, ATW, Indoor, Outdoor, One Push WB, Manual WB, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor/Auto)
GainAuto/Manual (0dB to 33dB) Max. Gain Limit (9dB to 33dB)
Wide Dynamic RangeNo
Backlight CompensationYes
Privacy Zone MaskingYes
Character Generator20 characters/line, max. 11 lines
Focus SystemAuto (Sensitivity: normal, low), One-push AF, Manual, Interval AF, Zoom Trigger AF,Focus compensation in ICR on
Camera Operation / Zoom Switch12x (144x with optical zoom)
Picture EffectsE-Flip, Black & White, Mirror image, Color enhancement
Exposure ControlAuto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation
Video Output SpecificationsDetail:
Lens Value12x optical zoom, f = 3.9 mm (wide) to 46.8 mm (tele), F1.8 to F2.0
Minimum IlluminationColor: 0.75 lx (F1.8, AGC on, 1/30 s) High Sensitivity Mode
Color: 3 lx (F1.8, AGC on, 1/30 s) Normal Mode
Interfaces SpecificationsDetail:
Camera Control InterfaceVISCA (CMOS 3.1 V level) Baud rate: 9.6 Kbps, 19.2 Kbps, 38.4 Kbps, 57.6 Kbps, 115.2 Kbps, Stop bit: 1 bit
General SpecificationsDetail:
Dimensions (W x H x D)60mm x 64mm x 105mm
Weight385 grams
Operating Temperature-5 to +60 (°C) / 20 (%) to 80 (%) Absolute Humidity: 36 (g/m3)
Storage Temperature-20 to +60 (°C) / 20 (%) to 95 (%) Absolute Humidity: 36 (g/m3)
Operating Humidity20% to 80% Absolute humidity : 36[g/m3]
Storage Humidity20% to 95% Absolute humidity : 36[g/m3]
Power Consumption2.8W (Typ. DC IN 6 - 12V, steady state)
Power Requirements6.0V ~ 12.0V DC
